Blackmagic Design | ATEM 2 M/E Constellation 4K | Production Switcher
The Blackmagic Design ATEM 2 M/E Constellation HD is a professional-grade live production switcher built for modern multi-camera environments. Equipped with 20 independent 3G-SDI inputs (each with standard conversion) and 12 3G-SDI outputs, it delivers powerful routing flexibility and seamless broadcast-quality switching. Designed for HD workflows, it includes built-in multiview, SuperSource layering, chroma keying, a Fairlight audio mixer, and integrated talkback to streamline production setups.
Ideal for studio, live events, or streaming applications, it features support for 16-window multiview monitoring, a high-performance 48-channel Fairlight mixer, and built-in USB-C webcam output for plug-and-play use with streaming platforms. The ATEM 2 M/E Constellation HD also integrates up to eight chroma/luma keyers, two DVEs, and extensive media pool support for stills and animations, offering a powerful solution for real-time graphics and effects.
Features
- Supports 3G/HD-SDI workflows with 10-bit broadcast quality
- 20 x 3G-SDI inputs with frame sync, format and frame rate conversion
- 12 x 3G-SDI outputs with assignable aux control
- 16-window multiview with labels and audio meters
- USB-C webcam output for direct streaming integration
- Two built-in DVEs and powerful SuperSource layering
- 8 x upstream and 2 x downstream keyers, including advanced chroma/luma keying
- 48-channel Fairlight audio mixer with EQ and dynamics
- Media pool with 40 stills and 400-frame animations
- Integrated talkback with XLR, RJ12 and SDI camera return support
- Front panel control, ATEM Software Control, or optional ATEM hardware panels
- Compatible with Blackmagic�s ATEM Advanced Panels and ATEM Camera Control
